Керований (L2) комутатор з 24-ма портами 10/100/1000Mbps PoE+ та 4-ма комбо-портами 100/1000Mbps combo (RJ-45/SFP) . Сукупний PoE бюджет – 250Вт.
UTP3328TS-PSB280-L2
18 705,00 грн.
Керований (L2) комутатор з 24-ма портами 10/100/1000Mbps PoE+ (вихідне живлення до 30Вт на порт) та 4-ма комбо-портами 100/1000Mbps combo (RJ-45/SFP) . Сукупний PoE бюджет – 250Вт.
| Керування | L2+ |
|---|---|
| LAN порти | 24 |
| Швидкість портів LAN | 10/100/1000Мбіт/с |
| Uplink RJ-45 | 4 |
| Uplink SFP | 4 |
| Uplink Combo порти | 4 |
| Підтримка PoE | 30Вт (802.3af/at) |
Всі характеристики
| Items | UTP3320TS-PSB-L2 | UTP3328TS-PSB280-L2 | UTP3328TS-PSB-L2 |
| Hardware Specifications | |||
| Downlink Port | 16*10/100/1000Base-T PoE+ RJ-45(Auto-MDI/MDI-X) | 24*10/100/1000Base-T PoE+ RJ-45(Auto-MDI/MDI-X) | |
| Uplink Port | 4*1000M Combo (RJ-45/SFP) | ||
| Console port | 1*RJ-45 | ||
| LED Indicators | 1*PWR, power supply indicator 1*SYS, system working indicator 20*Link, port state indicators 16*PoE, port PoE state indicators |
1*PWR, power supply indicator 1*SYS, system working indicator 28*Link, port state indicators 24*PoE, port PoE state indicators |
|
| Dimensions (W*D*H) | 440mm*315mm*44mm | ||
| Input Voltage | 100~240V AC, 50~60Hz | ||
| Power Consumption | ≤280W (Full load including PoE) | ≤450W (Full load including PoE) | |
| Material | Metal shell | ||
| Installation | Rack/Desktop/Wall mounted | ||
| Switch Property | |||
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at | ||
| Forwarding Modes | Store and Forward | ||
| MAC Table | 8k, support auto learning | ||
| Switching Capacity | 40Gbps/non-blocking | 56Gbps/non-blocking | |
| Packet Forwarding Rate | 29.7Mpps | 41.6Mpps | |
| Jumbo Frame | 9kB | ||
| Power Supply | |||
| PoE Standard | IEEE 802.3af/at | ||
| PoE Power Supply Type | End-span | ||
| PoE Pin Assignment | 4/5(+), 7/8(-) | ||
| PoE Budget | 30W max for each port, 250W max for whole switch | 30W max for each port, 400W max for whole switch | |
| Reliability | |||
| Surge | IEC61000-4-5, line to earth: 4kV | ||
| ESD | IEC61000-4-2, Level 3: Contact Discharge: +6kV, Air Discharge: +8kV | ||
| Operating | 0℃~45℃, 10%~90% (Non-condensation) | ||
| Storage | -40℃~70℃, 5%~90% (Non-condensation) | ||
| Software Architecture | |||
| VLAN | Port-based VLAN, 802.1Q-based VLAN, Protocol-based VLAN, MAC-based VLAN, Multicast-based VLAN | ||
| Access mode, Trunk mode , Hybrid mode | |||
| Max. 4094 VLAN | |||
| QinQ | Basic QinQ, Flexible QinQ | ||
| Priority replication and mapping | |||
| MAC address copy | |||
| Layer 2 protocol transparent transmission | |||
| LACP | LACP mode, Manual mode | ||
| Each link aggregation group has no less than 8 ports, No less than 8 link aggregation groups per switch | |||
| LLDP | Support LLDP | ||
| Spanning Tree | STP, RSTP, MSTP | ||
| Loopback | Port based, VLAN-based | ||
| PoE | Port PoE configuration | ||
| PoE scheduled management | |||
| PoE Watchdog | |||
| Storm Control | Broadcast storm control, Multicast Storm Control, Unknown unicast storm control | ||
| QoS | Inbound speed limit, Outbound speed limit | ||
| Speed limit based on access contro | |||
| CoS-to-DSCP, DSCP-to-CoS, PQ, WRR, SP + WRR | |||
| ACL | MAC-based ACL, IPV4-based ACL, IPV6-based ACL, Protocol-based ACL | ||
| Security Feature | IP + port, MAC + port, IP + MAC, IP + MAC + port, IP + VLAN, MAC + VLAN, IP + MAC + VLAN, IP + MAC + VLAN + port | ||
| Port maximum MAC address learning control | |||
| DHCP snooping | |||
| IP source guard | |||
| Port Isolation | Support port isolation | ||
| Port Mirroring | One-to-one mirroring | ||
| Many-to-one mirroring | |||
| IGMP Snooping | IGMP snooping V1, V2, V3 | ||
| Static Routing | Multiple interface VLANs | ||
| IPV4 static routing | |||
| IP Protocol | IPV4, IPV6 | ||
| SNMP | |||
| Syslog | |||
| Telnet, ssh, http, https | |||
| DHCP server, DHCP client | |||
| AAA | |||
| Radius | |||
| TACACS+ | |||
Документація
